Premium Freestanding Fabric LED Lightbox
- Premium LED freestanding Lightbox
- Available in 3 sizes - 1m, 2m or 3m wide
- Supplied flat packed - easy allen key assembly
- Up to 22,000 hours of illumination
- Vibrant LED Edge lit strip lighting
- Premium SEG graphics - vibrant & easy to update
- Choose single or double sided graphics
- Single-sided graphic comes with a black back rear to retain light
- Generous 3m power lead
- Twin feet to ensure optimum stability
- UK manufactured
- Anodised aluminium frame is 125mm deep
- 100mm frame and 150mm frame also available on request
- 1000 (w) x 2000mm (h)
- 2000 (w) x 2000mm (h)
- 2000 (w) x 3000mm (h)
The slim design makes the graphic the centre of attention rather than the frame. With this freestanding lightbox is available in three different sizes which can all be connected together to make a large scale seamless back wall.
Each graphic is finished with a silicon edge that simply pushes into a channel of the edge of the frame. No tools and no fuss when it comes to changing your marketing message in-store. The lightboxes have the advantage of edge-lit LED technology with an expected lamp life of around 22,000 hours. The LED lights are attached inside the edge of the box to give an even light across the image.
The transformer and cables are well hidden in the frame so it does not distract from your graphic. Each lightbox is delivered flat packed but is easily assembled using the instructions and Allen key provided.
Your lightbox is supplied with a transformer (DC24 volt output) which powers the LED light strips. Each LED strip of lights is 360mm long and draws a total of 13 Watts. The number of LED light strips and transformers will vary according to the size of the lightbox. Only one mains cable and the plug is required regardless of the number of transformers used.
The LED lightbox is ideal for visual merchandising and as an alternative to backdrops for exhibitions. It is incredibly versatile and can be used in retail, shopping centres, showrooms and entertainment venues. It uses the latest LED technology to give excellent high-quality lighting. The SEG graphic fixes into the channel on the frame and the UV printed graphic panel provides a clear and vibrant artwork. The frame allows graphics to be added on either side to give you double the visibility at only a small cost.
|Product Name||Premium Freestanding Fabric LED Lightbox|
|Hardware Guarantee||1 Year Hardware Guarantee|
|Width||1000mm, 2000mm, 3000mm|
|Depth||125mm (Excluding feet)|
|Delivery / Availability||4-7 Days Delivery|
|Indoor / Outdoor||Indoor|
|Portrait or Landscape||Landscape|
|Sided||Single or Double sided|
Whether you're a novice or a professional when it comes to artwork, we're here to give you the guidance needed to make sure your end result is print perfect.
If you have the elements, such as text, logos, and text, we can take these and create a print ready design layout for you at a small additional cost. We have a number of affordable set price packages available to suit any requirements. Many of our products have a design service as an additional extra for instant ordering. For products that don't please contact us to discuss your brief. Visit our in-house design service page to find out more.
Many of our print products have the option to upload your artwork on the product page. If that option is not available, you will receive an email shortly after placing your order with instructions on how to send your artwork files.
In order to avoid any delays in production, please follow our guidelines below to make sure your artwork is ready to go. If you have any questions, please don't hesitate to get in touch to talk to one of our team.
Resolution - 100dpi At Full Size
Generally, 100 dpi is a good standard for images with the document size set at full size of the large format printed product. For example, if you want to order a 40"×60" print, the image size should be 4000 pixels (40 x 100) by 6000 pixels (60 x 100) at 100 dpi.100% scale at 100 dpi
50% scale at 200 dpi
25% scale at 400 dpi
10% scale at 1000 dpi
If any dimension of the product is greater than 5000mm, please produce the artwork to scale. For very large artwork such as hoarding walls, 10% scale can be utilised at 1000dpi for images, or use vectors as these will scale perfectly.
Bleed - 5mm All Around At The Final Print Size
If you are creating set size artwork for hardware then please use the product template. If you have ordered a custom size product please ensure you include 5mm of bleed on your design.
You only need to add print bleed to your artwork if the design extends to the edge of the page. If all of your text and images are in the centre of the design and are surrounded by a plain white background, you won’t need to worry about print bleed as the edges will blend seamlessly into your overall design. If any element of the design goes right up to the edge of the page, a 5mm bleed on all sides is necessary.
Colours - Please Supply All Colours As CMYK+
Computer screens use RGB, while printers use CMYK. You may ask why this matters? Most colours created in RGB can be closely matched in CMYK but some cannot. If colours are critical we always suggest ordering a printed proof.
Other things you can do to check your colours:- Use a calibrated monitor (colours vary from monitor to monitor)
- Use a printed CMYK colour swatch to check your colours
- Don't check samples from a desktop printer
- Order a printed proof from us (this may cause an increase in lead time)
Fonts - Please Embed, Flatten, Or Convert To Curves
For large format print, we recommend that the minimum font site is 8pt (point size).
Our preferred file format for print-ready artwork is a PDF, please make sure you embed any fonts for perfect results. With other file formats please ensure fonts used in your design are converted to outlines and include all fonts and images used when you send your files to us.
Do You Need A Proof?
If you are providing print ready artwork, we do not provide a proof as standard, which enables us to get your print to you quicker. If you require a proof please get in touch with us to discuss. We do provide a free technical file check as standard, as outlined below.
We can provide a machine print proof for the extra cost of £25 plus delivery. This involves printing an A3 proof on the machine that will be used to produce your final print. This will give you an accurate representation of colour. If you are using our design service, we do send out a PDF proof, which is an accurate representation of content and positioning. It is not an exact indicator of the final colour due to the limitations of screens.
Quoted delivery dates for print are from approval of artwork, so please bear in mind that requesting a proof may delay the delivery date of your product.
After you have placed your order a provisional despatch and delivery date will be sent to you via email.
Our standard delivery time for printed products is 2-5 working days after artwork has been approved for print. If you have a specific deadline, please contact us to ensure we can meet this. Please check that your artwork meets the guidelines above to prevent any delays in approval.
Free Artwork Check
Before we go to print, we will carry out a free technical check on your artwork. If there are any issues, we will contact you to let you know what needs to be changed.
Our printers and media are of the highest standard and are carefully calibrated to produce vibrant, full colour prints. The process involves CMYK printing and this means it is not always possible to match Pantone colours, but they will be converted to the nearest CMYK equivalent.
If exact colour matching is critical, please send us a physical copy of other printed material, such as a letterhead or brochure, and we will check your file prior to printing. If we cannot achieve a reasonable match we will call you to discuss.
Please send any physical examples to: Discount Displays, 31-35 Wortley Road, Croydon, Surrey, CRO 3EB.
Need more help? Check out our full artwork preparation guide below:
If you want to ask a question about this product please contact us via the livechat button on the side of the page, call us on 020 8664 5660 or e-mail us at firstname.lastname@example.org.
