High Brightness 43" Digital Outdoor Pavement Sign
Product Code:
DIG-OUTABOARD-HB
Check out our New High Brightness Digital Outdoor Pavement Sign. With the same modern styling, this new and improved version boasts a 1500cd/m2 screen that is 5x brighter than your domestic TV. It still packs in all the features including being fully weatherproof, a 27 hour battery life and great portability. Read More
Price from £2,895.00
2-3 Working Days Delivery
3 Year Hardware Guarantee
Key Features:
- High Brightness Digital Pavement Sign
- 1500cd/m2screen (double brightness of standard)
- Greater impact in the dark & easier to read in the light
- Lightweight yet durable housing is ideal for outdoor use
- IP65 rated - giving complete weatherproofness
- Robust castors make for easy movement
- 43" screen with tempered glass - non-glare & easy to read
- HD 1080x1920 resolution screen - 1,2000:1 contrast ratio
- Built in locking bar for safety in public spaces
- 27 hours of run time, from only 7 hours of charging (Can be mains powered)
- Integrated android media player for easy updates via USB
- Optional network upgrade and CMS access to update remotely
- Suitable for indoor or outdoor use
- Includes 2x 5W speakers for audio
- Dimensions:
- See below for full dimensions
Check out our upgraded 43" outdoor digital pavement sign. Packed with the same styling and features as our incredibly popular unit, it comes with a higher brightness display for greater visibility and readability. It has an upgraded 1500cd/m2 screen with a 1200:1 contrast ratio. It also has a built in sensor to adjust the brightness for all conditions. The brighter screen means it is more visible in the dark and easier to read in sunny conditions. The screen is even tempered and has anti-glare properties.
The rugged IP65 casing is fully weatherproof and ideal for indoor or outdoor use. It includes a long life battery which can run for up to 27 hours on a 7 hour charge. It can also be mains powered for 24/7 use. It includes durable wheels, which are designed to reduce shaking when in use. This makes it incredibly easy to manoeuvre and store overnight.
The impressive unit packs a build in Android media player and dual 5W speakers to the Full HD 1080p screen. You can either update the screen via USB or upgrade to the network upgrade and CMS access for wireless updating from any location!
Option
Overall size
Weight
Unit size
1197.8 (h) x 603.2 (w) x 487.5mm (d)
46.2kg
Package size
1430 (w) x 753 (h) x 643mm (d)
62kg
| Product Name | High Brightness 43" Digital Outdoor A-board |
|---|---|
| SKU | DIG-OUTABOARD-HB |
| Hardware Guarantee | 3 Year Hardware Guarantee |
| Delivery / Availability | 2-3 Working Days Delivery |
| Graphic Size | Other Sizes |
| Indoor / Outdoor | Outdoor |
| Weight | 46.2kg |
| Depth | 487.5mm |
| Height | 1197.8mm |
| Width | 603.2mm |
| Frame Finish | Black |
Whether you're a novice or a professional when it comes to artwork, we're here to give you the guidance needed to make sure your end result is print perfect.
I don't have print ready artwork, can you design it for me?
If you have the elements, such as text, logos, and text, we can take these and create a print ready design layout for you at a small additional cost. We have a number of affordable set price packages available to suit any requirements. Many of our products have a design service as an additional extra for instant ordering. For products that don't please contact us to discuss your brief. Visit our in-house design service page to find out more.
I will be supplying print ready artwork.
Many of our print products have the option to upload your artwork on the product page. If that option is not available, you will receive an email shortly after placing your order with instructions on how to send your artwork files.
In order to avoid any delays in production, please follow our guidelines below to make sure your artwork is ready to go. If you have any questions, please don't hesitate to get in touch to talk to one of our team.
Resolution - 100dpi At Full Size
Generally, 100 dpi is a good standard for images with the document size set at full size of the large format printed product. For example, if you want to order a 40"×60" print, the image size should be 4000 pixels (40 x 100) by 6000 pixels (60 x 100) at 100 dpi.
100% scale at 100 dpi50% scale at 200 dpi
25% scale at 400 dpi
10% scale at 1000 dpi
If any dimension of the product is greater than 5000mm, please produce the artwork to scale. For very large artwork such as hoarding walls, 10% scale can be utilised at 1000dpi for images, or use vectors as these will scale perfectly.
Bleed - 5mm All Around At The Final Print Size
If you are creating set size artwork for hardware then please use the product template. If you have ordered a custom size product please ensure you include 5mm of bleed on your design.
You only need to add print bleed to your artwork if the design extends to the edge of the page. If all of your text and images are in the centre of the design and are surrounded by a plain white background, you won’t need to worry about print bleed as the edges will blend seamlessly into your overall design. If any element of the design goes right up to the edge of the page, a 5mm bleed on all sides is necessary.
Colours - Please Supply All Colours As CMYK+
Computer screens use RGB, while printers use CMYK. You may ask why this matters? Most colours created in RGB can be closely matched in CMYK but some cannot. If colours are critical we always suggest ordering a printed proof.
Other things you can do to check your colours:
- Use a calibrated monitor (colours vary from monitor to monitor)- Use a printed CMYK colour swatch to check your colours
- Don't check samples from a desktop printer
- Order a printed proof from us (this may cause an increase in lead time)
Fonts - Please Embed, Flatten, Or Convert To Curves
For large format print, we recommend that the minimum font site is 8pt (point size).
Our preferred file format for print-ready artwork is a PDF, please make sure you embed any fonts for perfect results. With other file formats please ensure fonts used in your design are converted to outlines and include all fonts and images used when you send your files to us.
Do You Need A Proof?
If you are providing print ready artwork, we do not provide a proof as standard, which enables us to get your print to you quicker. If you require a proof please get in touch with us to discuss. We do provide a free technical file check as standard, as outlined below.
We can provide a machine print proof for the extra cost of £25 plus delivery. This involves printing an A3 proof on the machine that will be used to produce your final print. This will give you an accurate representation of colour. If you are using our design service, we do send out a PDF proof, which is an accurate representation of content and positioning. It is not an exact indicator of the final colour due to the limitations of screens.
Quoted delivery dates for print are from approval of artwork, so please bear in mind that requesting a proof may delay the delivery date of your product.
Delivery
After you have placed your order a provisional despatch and delivery date will be sent to you via email.
Our standard delivery time for printed products is 2-5 working days after artwork has been approved for print. If you have a specific deadline, please contact us to ensure we can meet this. Please check that your artwork meets the guidelines above to prevent any delays in approval.
Free Artwork Check
Before we go to print, we will carry out a free technical check on your artwork. If there are any issues, we will contact you to let you know what needs to be changed.
What's Included
What's Not Included
- File format
- File size
- Resolution
- Fonts
- Colours
- Spelling and Grammar Mistakes
- Positioning
Colour Matching
Our printers and media are of the highest standard and are carefully calibrated to produce vibrant, full colour prints. The process involves CMYK printing and this means it is not always possible to match Pantone colours, but they will be converted to the nearest CMYK equivalent.
If exact colour matching is critical, please send us a physical copy of other printed material, such as a letterhead or brochure, and we will check your file prior to printing. If we cannot achieve a reasonable match we will call you to discuss.
Please send any physical examples to: Discount Displays, 31-35 Wortley Road, Croydon, Surrey, CRO 3EB.
Need more help? Check out our full artwork preparation guide below:
Is the product suitable for indoor use?
Yes. The high brightness digital pavement sign can be used indoors or outdoor, it even features an ambient light sensor to adjust the screen brightness depending on the environment it is placed in. Its high brightness screen is ideal for outdoor use in bright settings for great readability.
How long does the battery last?
The integrated lithium polymer battery is rated to last for 27hrs, however, some media played on the digital signage software and running the digital A-board at full brightness will negatively affect the battery life, therefore, you may only get 14hrs of use on a single charge. Regardless, you can use the smart charge level indicator at the rear of the display; which gives an accurate estimate of the remaining battery life, so no unexpected shutdowns occur.
How bright is the screen?
The high brightness version is 1500cd/m2, which is roughly 5 times brighter than your standard TV, and double the standard version, providing you with a high visibility digital signage solution.
Can I run the display from mains power rather than the battery?
Yes. If you are wanting to run the display via the mains you just need to plug in the supplied power adapter and you're good to go, this could be a suitable solution if you wish to display the A-board inside as a menu board.
Yes. The high brightness digital pavement sign can be used indoors or outdoor, it even features an ambient light sensor to adjust the screen brightness depending on the environment it is placed in. Its high brightness screen is ideal for outdoor use in bright settings for great readability.
How long does the battery last?
The integrated lithium polymer battery is rated to last for 27hrs, however, some media played on the digital signage software and running the digital A-board at full brightness will negatively affect the battery life, therefore, you may only get 14hrs of use on a single charge. Regardless, you can use the smart charge level indicator at the rear of the display; which gives an accurate estimate of the remaining battery life, so no unexpected shutdowns occur.
How bright is the screen?
The high brightness version is 1500cd/m2, which is roughly 5 times brighter than your standard TV, and double the standard version, providing you with a high visibility digital signage solution.
Can I run the display from mains power rather than the battery?
Yes. If you are wanting to run the display via the mains you just need to plug in the supplied power adapter and you're good to go, this could be a suitable solution if you wish to display the A-board inside as a menu board.
